Aztech HomePlug HL119EP AV 600Mbps Ethernet Adapter with Pass Through
Embarking on a concept of No New Wires® data communications, Aztech HL119EP transforms your in-house powerline into a networking infrastructure. Thus it successfully reduces "dead spot" and increases network coverage within your home. Works with any Wi-Fi router or wireless access point (product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or is non-standard or outdated)
Out Stock
- SKU:
- H88-D93061-A42
$35.00
Selected: Aztech HomePlug HL119EP AV 600Mbps Ethernet Adapter with Pass Through
$35.00
Specifications
| Standards | 1) IEEE 1901/HomePlug AV Compliant
2) Co- existence with HomePlug 1.0 Nodes 3) Compliant to EuP requirements 4) IEEE 802.3 10/100/1000 Ethernet (1 Gbps) 5) IEEE 802.3az support |
|---|---|
| Data Transfer Rate | Up to 600 Mbps over powerline |
| Protocols | CSMA/CA over powerline in your home |
| Modulation Support | 1) OFDM 4096
2) OFDM 1024 3) OFDM 256 4) OFDM 64 5) OFDM 16 6) OFDM 8-QAM 7) QPSK 8) BPSK 9) ROBO |
| Frequency Band | 2MHz to 68MHz band |
| Quality of Service (QoS) | 1) Priority-based CSMA/CA channel access schemes maximize efficiency and throughput
2) Integrated Quality of Service (QoS) Enhancements 3) Hardware Packet Classifiers for ToS, CoS and IP Port Number 4) Supports IGMP managed multicast session |
| Diagnostic and Management Interface | Homeplug AV generic and vendor specific Management Message Entries (MME) |
| Security Support | 128-bit AES Link Encryption with key management |
| Memory | SPI Flash : 2 MB |
| AC Pass Through Power Socket | Current Rating: 13A max (UK)
16A max (DEU) 10A max (AUS) |
| Platform Support | ≤ OS Independent with TCP/IP protocol installed |
| Hardware | Atheros AR7450 + AR1540 chipset |
| Power Supply | Switch Mode 85VAC-265VAC Supply for UK/US 3-pin plugs |
| LED Indicators | 1) 1 x Power LED (Green color)
2) 1 x Powerline Link/Activity Status LED (Bicolor) 3) 1 x Ethernet Link/Activity Status LED (Green color) |
| External Connectors | 1) 1 x Electrical Power plugs
2) 1 x RJ45 for 10/100/1000 Ethernet |
| Push Button/Switch | 1 x Configuration Push Button (for Simple Connect and Factory Default Reset) |
| Resin/Plastic Casing | 1) Polycarbonate
2) FR rating UL94-V0 |
| Dimension | 116(H) x 62(W) x 42(D) mm |
| Weight | 210g |
| Power Consumption | 4.5W |
| Operating System | 1) Windows 98SE
2) Windows 2000 3) Windows ME 4) Windows XP 5) Windows Vista 32bit 6) Windows 7 (32/64-bit) 7) Windows 8 |
| Temperature | 1) Operating : 0° to 40° Celsius
2) Non-Operating : -25 ° to 70° Celsius |
| Humidity | 1) Operating : 30% to 80% RH (Non-Condensing)
2) Non-Operating : 30% to 95% RH (Non-Condensing) |
